KEY SPECS

Motherboard Support : Mini-ITX, Micro-ATX, ATX
Enclosure Type : Mid-Tower
Case Material : SGCC Steel, TUltra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)

DIMENSIONS

Height : 495mm (With Feet)
Width : 290mm
Depth : 466mm
Weight : 13.1 kg

COMPATIBILITY & CLEARANCE

CPU Cooler Clearance : Up to 165mm
GPU Clearance : Up to 435mm
PSU Clearance : 200mm
Cable Management : 91mm

FRONT I/O PORTS

USB 3.2 Gen 1 Type-A : 2
USB 3.2 Gen 2 Type-C : 1
Headset Audio Jack : 1

EXPANSION SLOTS

Standard : 7
Vertical : 0

DRIVE BAYS

2.5″ : 4+2
3.5″ : 2

FAN SUPPORT

Side : 3 x 120mm
Top : 3 x 120mm / 2 x 140mm
Bottom : 3 x 120mm / 2 x 140mm
Rear : 1 x 120mm
Filters : All Air Intakes

RADIATOR SUPPORT

Side : Up to 360mm
Top : Up to 360mm
Bottom : Up to 360mm
Rear : Up to 120mm

FAN SPECS

Model : F120Q (Case Version)
Speed : 1200 ± 240RPM
Airflow : 62.18 CFM
Static : 1.05 mm – H2O
Noise : 25.1 dBA
Fan Connector : 3-pin

FAN SPECS

Model : F120RGB Duo
Speed : 500 ± 1800RPM
Airflow : 48.58 CFM
Static : 2.42mm – H2O
Noise : 29 dBA
Fan Connector : 4-pin
